Product Details:
|
| Material: | Stainless Steel Sheet, HDP Galvanized Sheet | Surface Treatment: | Hot Dipped Galvanized, Stainless Stell |
|---|---|---|---|
| Type: | Razor Concertina Barbed Wire | Razor Type: | Concertina Coil |
| Application: | Security Fence | Wire Diameter: | 1.6-3.2mm |
| Packing: | Woven Bag | Barb Length: | 1.5-3.0cm |
| Highlight: | concertina razor barbed wire,razor coil barbed wire,razor sharp barbed wire |
||
BTO-22 CBT-65 Concertina wire galvanized blade wire stainless steel razor barbed wire wall fence
Razor Wire is the best solution When you need to get serious about security. Razor Wire is made of a corrosion resistant galvanized steel cutting ribbon wrapped around a core of galvanized spring steel wire. Razor Wire around the perimeter is enough to deter any wouldbe vandal, robber or saboteur. It's impossible to cut without highly specialized tools.
Material:Galvanized wire, PVC coated wire, Stainless steel wire, Hot Dipped Galvanized Sheet.
Razor wire is a mesh of metal strips with sharp edges whose purpose is to prevent passage by humans.
Razor wire is much sharper than the standard barbed wire.
Applications:
Razor Barbed Wire used in mainly serves in protecting of grass boundary, railway, highway and also widely used in military, jail, industry, agriculture, animal husbandry, dwelling house, plantation for fencing.
Specification:
| Reference Number |
Thickness (mm) |
Wire Dia (mm) |
Bard Length (mm) |
Bard Width (mm) |
Bard Distance (mm) |
| BTO-10 | 0.5±0.05 | 2.5±0.05 | 10±1 | 13± | 16±1 |
| BTO-12 | 0.5±0.05 | 2.5±0.05 | 12±1 | 15±1 | 26±1 |
| BTO-18 | 0.5±0.05 | 2.5±0.05 | 18±1 | 15±1 | 33±1 |
| BTO-22 | 0.5±0.05 | 2.5±0.05 | 22±1 | 15±1 | 34±1 |
| BTO-28 | 0.5±0.05 | 2.5±0.05 | 28±1 | 15±1 | 53+1 |
| BTO-30 | 0.5±0.05 | 2.5±0.05 | 30±1 | 21±1 | 54±1 |
| CBT-60 | 0.5±0.05 | 2.5±0.05 | 60±1 | 32±1 | 100±1 |
| CBT-65 | 0.5±0.05 | 2.5±0.05 | 65±1 | 21±1 | 100±2 |
Razor Barbed Wire Coil and Unit Loops
| Outside Diameter | No.of Loops | Standard Length Per Coil | Type | Notes |
| 450mm | 33 | 8M | CBT-65 | Single coil |
| 500mm | 41 | 10M | CBT-65 | Single coil |
| 700mm | 41 | 10M | CBT-65 | Single coil |
| 960mm | 53 | 13M | CBT-65 | Single coil |
| 500mm | 102 | 16M | BTO-10.15.22 | Cross type |
| 600mm | 86 | 14M | BTO-10.15.22 | Cross type |
| 700mm | 72 | 12M | BTO-10.15.22 | Cross type |
| 800mm | 64 | 10M | BTO-10.15.22 | Cross type |
| 960mm | 52 | 9M | BTO-10.15.22 | Cross type |
Packing & Delivery:
1. sheet is packed by pallet or strapped into bundle.
2. sheet in carton or wooden case.
3. rolls in water-proof paper+plastic film.
Producing department:
ANPING SHUXIN MANUFACTORY CO.,LTD,established in 2013.We are located in Anping county,Hebei province.Know as the hometown of Chinese wire mesh.
We are professional manufacturer and have professional technological.
Our mainly product: Chicken Cage, wire mesh basket, wire mesh container, defensive barrier, Gabion, razor wire, and barbed wire etc.
If you want to customize,please contact us.
