Product Details:
|
| Features: | Easy Installation, Suitable For Any Terrain | Name: | Wire Mesh Gabion Box |
|---|---|---|---|
| Material: | Galvanized Wire, PVC Wire, Galfan Wire | Weave: | Double Twist, Trible Twist |
| Mesh Wire: | From 2.4mm To 3.4mm | Selvage Wire: | From 3.0mm To 3.9mm |
| Biding Wire: | Common Use 2.2mm | Mesh Hole: | 60*80mm, 80*100mm, Customized |
| Gabion Size: | 1*1*1m, 2*1*1m, 3*1*1m, 4*1*1m, 2*1*0.5m | Pakcage: | In Bundle ( After Compression) |
| Zinc Coating: | Around 275g/sq.mt | Usage: | Rive Protection, Retaing Wall, Flood Control |
| Highlight: | galvanized double twist gabion mesh basket,2mx1mx1m gabion mesh basket,gabion baskets 2mx1mx1m |
||
Galvanized Double Twist Hexagonal Wire Mesh Gabion Basket Stone Cage for Africa
Gabion basket / Gabion Box's raw material is " galvanized iron wire " or " PVC coated iron wire " or " galfan ( high zinc coating ) wire ", these raw material can well anti - rust, to make sure gabion box can using a very long time under the sea water, to help you finish the project in a very high efficient way. To a certain extent, it also helps you save costs.
| Gabion Basket Technical Data Sheet | ||||
| Material | Q195, Low Carbon Steel Wire | |||
| Weave Type | Double Twisted | |||
| Hole Shape | Hexagonal | |||
| Surface Treatment | Hot Dipped Galvanized | PVC Coated | ||
| Mesh Hole | 80 * 100 mm | 60 * 80 mm | 80 *100 mm | 60 * 80 mm |
| Mesh Wire | 2.2 - 3.0 mm | 2.0 - 2.7 mm | 2.2 / 3.2 - 3.0 / 4.0 mm | 2.0 /3.0 - 2.7 / 3.7 mm |
| Selvage Wire | 3.0 - 3.9 mm | 3.0 - 3.7 mm | 3.0 / 4.0 - 3.9 / 4.9 mm | 3.0 / 4.0 - 3.7 / 4.7 mm |
| Lacing Wire | 2.2 mm | 2.2 mm | 2.2 / 3.2 mm | 2.2 / 3.2 mm |
| Gabion Basket Size | 1 * 1 * 1 m, 2 * 1 * 1 m, 3 * 1 * 1 m, 4 * 1 * 1 *1 m, etc | |||
Features:
1. Easy to install, no special technology required.
2. 6 M/S strong anti - scour ability, able to withstand water, flow speeds up to 6 M/S
3. Good Ductility, no structural joints
4. High strength, withstand a wide range of deformation.
